| Parameter | Value |
|---|---|
| Model Number | LPJK9029A159NL |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications-Lan | 5G Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Yellow&Green - Yellow |
| Number of Cores per Jack | 8 |
| Shielding | Shielded |
| Number of Ports | Single Port |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C |
Package Details: 110 pcs in 1 tray, which is 34.5*34.5*27cm, 5.5KGS (550pcs) of each carton.
QWhat is the main application of the LPJK9029A159NL RJ45 connector?
The LPJK9029A159NL RJ45 connector is designed for high-performance LAN applications, specifically optimized for 5G Base-T and AutoMDIX capabilities.
QDoes this connector support Power over Ethernet (PoE)?
Yes, this RJ45 connector features an integrated transformer supporting Power over Ethernet (PoE) up to 50 Watts and transfer speeds up to 10 Gbit/s.
QWhat mounting and orientation configurations does it feature?
It uses a Through Hole mounting type (THT) with solder termination and has a 90° Angle (Right orientation) configuration with a Down tab direction.
QWhat standards are compliant with this RJ45 connector?
The component is fully compliant with standard networking protocols, including IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, and the upcoming IEEE 802.3bt standards.
QWhat are the packaging dimensions and weight?
The standard packaging is 110 pcs per tray (dimensions 34.5*34.5*27cm), with a total weight of 5.5KGS per carton containing 550pcs.
QWhat is the operating temperature range for this product?
The LPJK9029A159NL RJ45 connector has a standard operating temperature range from 0°C to 70°C, suitable for typical commercial environments.
