| Part No. | LS-SM313G-02C |
| Form Factor | SFP |
| Max Data Rate | 3.125Gbps |
| Wavelength | 1310nm |
| Max Cable Distance | 2km |
| Connector | Duplex LC |
| Media | SMF |
| Transmitter Type | FP |
| Receiver Type | PIN |
| TX Power | -8 ~ 0dBm |
| Receiver Sensitivity | < -18dBm |
| Receiver Overload | -1dBm |
| EMC (Electro Magnetic Compatibility) | Supported |
| DDM/DOM | Supported |
| Protocols | MSA Compliant |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
A complete series of optical modules is available for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
| Part Number | Data Rate | Wavelength | Distance | Media | DDM |
|---|---|---|---|---|---|
| LS-MM852G-S3C | 2.5Gbps | 850nm | 300m | Multi-mode | Yes |
| LS-MM852G-S5C | 2.5Gbps | 850nm | 550m | Multi-mode | Yes |
| LS-SM312G-02C | 2.5Gbps | 1310nm | 2km | Single Mode | Yes |
| LS-SM312G-10C | 2.5Gbps | 1310nm | 10km | Single Mode | Yes |
| LS-SM312G-15C | 2.5Gbps | 1310nm | 15km | Single Mode | Yes |
| LS-SM312G-20C | 2.5Gbps | 1310nm | 20km | Single Mode | Yes |
| LS-SM552G-20C | 2.5Gbps | 1550nm | 20km | Single Mode | Yes |
| LS-SM312G-40C | 2.5Gbps | 1310nm | 40km | Single Mode | Yes |
| LS-SM552G-40C | 2.5Gbps | 1550nm | 40km | Single Mode | Yes |
| LS-SM552G-80C | 2.5Gbps | 1550nm | 80km | Single Mode | Yes |
We provide end-to-end DWDM setups with a complete suite of optical devices—ranging from active modules to optical passive components. This covers optical amplifiers (EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP, and OTDR solutions.
To satisfy the high demands of massive data transmission inside data centers, we offer high-speed optical module products spanning rates from 10G to 800G, delivering reliable optical interconnection solutions.
Offering highly reliable, high-performance designs utilizing mature laser setups and mainstream chip solutions. Supported scenarios include Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul, and Back-haul links for 4G/5G systems.
Targeting global communication network builders, we provide full FTTx optical fiber access solutions encompassing all-optical and combined copper-optical access systems.
Ensuring the continuous health of communication networks, we deliver advanced optical cable operation and maintenance solutions that integrate optical line protection systems (OLP) and optical line monitoring systems (OLM).
We are a specialized manufacturer of magnetic telecom and network components, certified by ISO9001:2000, RoHS, REACH, CE and UL, utilizing advanced manufacturing equipment and testing gear imported from abroad. With abundant production capacity, we are fully equipped to deliver high-quality products within tight timeframes.
Additionally, we offer a comprehensive series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. Our portfolio also features high-speed optical interconnect designs for cloud computing systems and ultra-broadband networks. Applying the latest optoelectronic technologies, we design, manufacture, and distribute products worldwide.
